FOT-100 Fully Automatic Transformer Oil BDV Tester

FOT-100 Fully Automatic Transformer Oil BDV Tester

Model No.: FOT-100

FUOOTECH FOT-100 Oil Tester is for testing transformer oil's BDV value.

Testing range: 0 ~ 100 kV

Power Supply: AC220V ±10%, 50 HZ

Packing Details: In Standard Exportation Wooden Case

Delivery Time: 15 days

Payment Terms: T/T, L/C, Cash

Certification: CE, ISO, CCC

Inquiry Now

Detailed Description

Inquiry Now

Application:
FUOOTECH FOT-100kV fully automatic transformer oil BDV tester is apply to test the insulating oil's dielectric strength (BDV), which is designed as per the requirement of IEC165 Testing Method of Insulation Oil Medium Strength, which via proper programming, has got functions of auto boosting, step down, stirring, display and print out. After breakdown of oil medium, HV break off will operate within 10 seconds to enable an auto isolation of control system partly; this effectively safeguards the personnel security and equipment safety.

FUOOTECH FOT-100kV fully automatic transformer oil BDV tester adopts industrial SCM to control which is applied to integrate circuit, new model I/0 connection , particular testing and anti-jamming technology which is largely improved the machine's capacity.

Features:
1. Simply operate: automatically
2. Menu controlled. Input data can be cleared.
3. Store 99 groups' oil testing data which is convenient to reading and print.
4. System time can go on running under power off;
5. Upgrading software through RS232 available
6. High capacity of anti-jamming and high precision of testing.
7. Small volume, light, convenient to operate outside.

Technology and parameter data
1. Power supply: AC220V ±10%, 50 HZ
2. Output voltage: 100 kV
3. Capacity: 2.0 kVA
4. Pressure increase speed: about 2 kV/S
5. Voltage inspection accuracy: 3%
6. Dielectric strength sensitivity: <2KV

7. Wave from distortion: < 3%

8. Breakdown response time: <10ms
9. Polar distance: 2.5mm
10. Working environment: temperature: 0 to 40 º C, humidity: < 85% (Relative Humidity)
11. Storage environment: temperature: -20 to 60 º C, humidity: < 75% (Relative Humidity)

12. Working Altitude: < 1500 meters. (If over 1500m, it can be customized)

13. Dimensions and weight: 38 x 37 x 38 cm. Ne weightt: 40 kg (Approximately)
