Flow Rate: 3000 L/hr
Designed for: Filtering waste cooking oil, vegetable oil, palm oil, coconut oil, swill oil, animal oil etc.
Power Supply: 380V, 50Hz, 3Phase
Packing Details: in Standard Plywood Case
Delivery Time: 15 days
Terms of Payment: T/T, L/C, Western Union, Cash, Wechat Pay, Alipay, etc.
Certificate: CE, ISO, CCC, SGS
Brief Introduction:
This machine is special for filtering
waste cooking oil, dirty vegetable oil, palm oil, coconut oil, trench oil,
swill oil, animal oil etc. It effectively removes particles, water, acid
and alcohol etc. from the waste oil. The treated oil is clean, limpidity,
and with good smell, so as to reach the edible standard again.
Series
COP-B is a good recycling machine for fried food factory, oil
restaurant, cooking oil factory, vegetable oil factory, soap production,
biodiesel production, and waste oil collecting store.
This is a pre-treatment process of producing biodiesel, helping clients clean
the used cooking oils by removing particles, water content, gas content, etc…
This oil recycling machine is also installed a Plate Pressure system as extra option to separate the sundry goods, big-size particles and water from the oil quickly and effectively if the oil contains too many particles.
Two primary filters and fine filter combined for removing various sizes of impurities thoroughly. Next, the machine adopts highly vacuum system to dewater and degas. In addition, this machine use stainless steel filter element, it resists the acid in oil strongly. So, the used cooking oil was recycled by machine and become clean.
According to treated oil usages, there're
different machine bodies for you. For edible usage, we suggest choosing full
stainless steel body; for industrial, we suggest choosing carbon steel body.
Oil Result after Purification
|
Moisture (water content) |
≤100 PPM
(remove 100% of free water and 99%of
dissolved/emulsified water)
|
|
Gas Content |
≤0.01% |
|
Suspended Particles (Filtration precision) |
≤ 5 micron |
|
Demulsification |
New oil≤15min, running oil≤30min |
|
Cleanliness |
≤NAS 1638-Grade 5 |
Features:
1. Equipped with strong press filter, remove the big or tiny impurities.
2. Equipped with high vacuum oil filtration system along with three stages of
stainless steel material filters.
3. Special water separator filter mainly removes the mass water from the waste
cooking oil.
4. Adopts three-dimensional duplex evaporation and film evaporation
to separate and remove tiny water, soluble water, acid, alcohol, other
volatility liquid, etc., completely and effectively.
5. Efficient electric heating system, heating uniformity, less power
consumption, safe, and reliable.
6. Adopts interlocked protective system, which connect oil pump, heater
and liquid level sensor, avoiding blank heating, blank pumping, oil leak and
electricity leak.
Technical Specification:
|
Unit |
COP-B-10 |
COP-B-20 |
COP-B-30 |
COP-B-50 |
COP-B-100 |
COP-B-150 |
COP-B-200 |
COP-B-300 |
|||
|
Flow rate |
L/H |
600 |
1200 |
1800 |
3000 |
6000 |
9000 |
12000 |
18000 |
||
|
Vacuum degree |
Mpa |
-0.06 ~ - 0.095 |
|||||||||
|
Working pressure |
Mpa |
≤0.4 |
|||||||||
|
Temperature Control Range |
ºC |
0 ~ 100 |
|||||||||
|
Operation Temperature |
ºC |
50 ~ 70 |
|||||||||
|
Demulsification |
Min |
New oil≤15min, running oil≤30min |
|||||||||
|
Power supply |
380 VAC, 50 Hz, 3 Phase (or as per required) |
||||||||||
|
Working noise |
DB (A) |
≤ 65 ~ 90 |
|||||||||
|
Electric heating power |
KW |
18 |
24 |
26 |
30 |
48 |
60 |
96 |
135 |
||
|
Total electric power |
KW |
19.3 |
25.3 |
27.6 |
32.6 |
56 |
69 |
106.5 |
147 |
||
|
Inlet (outlet) caliber |
mm |
Ф25 |
Ф25 |
Ф25 |
Ф32 |
Ф42 |
Ф50 |
Ф50 |
Ф60 |
||
|
Dimension |
mm |
1500 x1000 |
1550 |
1600 |
1600 |
1750 x1250 |
1900 |
1900 |
2100 |
||
|
Weight |
Kg |
450 |
550 |
600 |
750 |
850 |
1000 |
1200 |
1500 |
||
Note: 1. The dimension and
weight will be changed with changing of technical specs.
2. All the specs can be
customized according to client's requirements.
